Crank reels

Description

EM050

Dimensions: W280xD185xH360mm
Weight: 1.7kg
Ø cheeks: 280 mm
Ø of the barrel: 105 mm
Useful width: 90 mm
Material: Frame and cheeks in galvanized steel with plastic coating

Indicative capacities according to the Ø of the cable:
- 5mm: 70m
-10mm: 50m
- 15mm: 20m

Code EM050

EM050P

Dimensions: W280xD185xH360mm
Weight: 1.7kg
Ø cheeks: 280 mm
Ø of the barrel: 105 mm
Useful width: 90 mm
Sockets: 3 female sockets 2P-T
Material: Frame and cheeks in galvanized steel with plastic coating

Indicative capacities according to the Ø of the cable:
- 5mm: 70m
- 10mm: 50m
- 15mm: 20m

Code EM050P

EM060

Dimensions: W280xD190xH365mm
Weight: 1.2kg
Ø cheeks: 275 mm
Ø of the barrel: 100 mm
Useful width: 105 mm
Material: Steel frame, plastic drum

Indicative capacities according to the Ø of the cable:
- 7mm: 100m
- 10mm: 60m
- 15mm: 30m

Code EM060

EM100

Dimensions: W550xD380xH625mm
Weight: 17kg
Ø cheeks: 475 mm
Ø of the barrel: 250 mm
Useful width: 290 mm
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 100m
- 15mm: 57m
- 20mm: 42m
- 30mm: 21.5m

Code EM100

EM100R

Dimensions: W550xD380xH625mm
Weight: 17kg
Ø cheeks: 475 mm
Ø of the barrel: 250 mm
Useful width: 290 mm
Wheels: Supplied with 4 castors Ø 80 mm
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 100m
- 15mm: 57m
- 20mm: 42m
- 30mm: 21.5m

Code EM100R

EM230

Dimensions: W540xD440x H465mm
Weight: 13.85kg
Ø cheeks: 398 mm
Ø of the barrel: 150 mm
Useful width: 350 mm
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 230m
- 15mm: 150m
- 20mm: 80m
- 30mm: 36m

Code EM230

EM230R

Dimensions: W540xD440x H465mm
Weight: 16.35kg
Ø cheeks: 398 mm
Ø of the barrel: 150 mm
Useful width: 350 mm
Wheels: Supplied with 4 castors Ø 100mm, 2 of which lock
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 230m
- 15mm: 150m
- 20mm: 80m
- 30mm: 36m

Code EM230R

EM320

Dimensions: W680xD440xH465mm
Weight: 14.4kg
Ø cheeks: 395 mm
Ø of the barrel: 147 mm
Useful width: 485 mm
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 320m
- 15mm: 210m
- 20mm: 120m
- 30mm: 52m

Code EM320

EM320R

Dimensions: W680xD440xH465mm
Weight: 16.9 kg
Ø cheeks: 395 mm
Ø of the barrel: 147 mm
Useful width: 485 mm
Wheels: Supplied with 4 castors Ø 100mm, 2 of which lock
Material: Frame and side panels in epoxy-finish steel

Indicative capacities according to the Ø of the cable:
- 10mm: 320m
- 15mm: 210m
- 20mm: 120m
- 30mm: 52m

Code EM320R
