Ultra-thin endoscope 0.9mm TITAN (TTS-YJ0.9PW)
Description
The thinnest endoscope in the TITAN range, with its extreme thinness of 0.9mm, lets you squeeze into any space. Designed to meet the most demanding requirements, it features a x6 zoom and interchangeable hose, so you can adapt to any situation.
- Extremely thin 0.9mm camera
- Fiber optic lighting
- 6x zoom
- Interchangeable hose
- 5” touchscreen
Technical details
Camera :
- Camera head : 0.97mm diameter
- Image sensor : 1/18” CMOS
- Resolution : 400 x 400 px
- Focus : 3 - 50mm
- Field of view : 120°
- Lighting : white optical fiber lighting
- Optics : optical glass
- Tightness : IP55
Control box :
- Dimensions : 15.5 cm x 13.9 cm x 5 cm
- Display : 5.0” LCD touchscreen (1024x768px)
- Battery : 2 x 3350mAh
- Storage : 64Gb max.
- Material : resistant ABS
- Charging current : 5V / 2A
- Brightness : manually adjustable
- White balance : adjustable
- Photo resolution : 400 x 400px (.jpg)
- Video resolution : 400 x 400px (.mov)
- Access keys : menu, playback, video, photo, brightness, x6 zoom
- Image selection : mirror image, preview, rotate
- Input / output : C-type
- Languages : 7 languages
- Net weight : 0.96kg
- Weight with case : 6kg
- Removable hose : yes
Flexible camera :
- Camera head orientation : all directions
- Hose length : 100cm
- Hose material : braided metal composite
Operating environment :
- Operating temperature :
- control box : -10°C ~ +40°C
- camera : -20°C ~ +60°C (preheating required below 1°C)
- Humidity : 15-90% frost-free
