STANDARD ACOUSTIC DOOR BLOCKS

With 60 years of experience in the field of acoustics, Boët StopSon offers a wide range of high performance acoustic door units (from Rw 50 to Rw 63dB).

Boët StopSon designs, manufactures and installs acoustic door units for a large number of applications, in particular for:

Technical or collective premises

Industrial premises

Test benches

Commercial buildings

Radio and television studios

Nightclubs & bars

Museums

Cinema complexes

Hospitals and clinics

Audiometry laboratories

Acoustic performance of the standard range from Rw 50 to Rw 63 dB

Tailor-made high-performance solutions

Certified performance from 50 to 63 dB

Custom dimensions up to 3000 x 3000 mm high

Customization of conception and design (single, double, triple, glazed, hatch, sliding, glazed)

Surface, rabbet or tunnel installation

Robust solutions built from 2mm thick steel sheets incorporating internal reinforcements to accommodate all types of equipment

Can be installed both indoors and outdoors

Flat threshold for easy access

Ultra-resistant lacquered finish (polyester powder paint – oven baking – RAL of your choice)

French made

Optimal acoustic sealing, guaranteed compression and a perfect finish

Between the partition and the frame, thanks to the design in 2 elements (frame + counter frame adjusted to the thickness of the partition)

Between the frame and the leaf, through one to three barriers of magnetic seals (depending on the model) on the entire periphery of the door unit

In the lower part of the door unit, thanks to our helical ramp hinges combined with an adjustable buffer system

A leaf core integrating a variable density multilayer complex

A wide choice of equipment and possible combinations

Boët StopSon takes full responsibility for the choice and quality of the equipment installed

All of our doorsets and equipment are assembled and tested in the factory

We offer a very wide choice of premium equipment from recognized equipment manufacturers

Quick and easy installation - Quickfix®

Our door units are delivered ready to install (equipment fitted in the factory & frame and leaves tested in the factory).

Our frames are pre-drilled and their installation on the civil engineering (or other type of partition) only requires a few minutes.

A frame / counter frame system taking up the full thickness of the partition allows an excellent finish around the entire periphery of the opening (in the context of a surface-mounted installation)

Each door unit is supplied with its complete fixing kit (sealant, screws, seals, mounting wedges, fixing covers) thus allowing reduced assembly time on site.

Our solutions are designed to adapt to any type of partition.

A unique design and a design adapted to each project

All the studies are carried out on our CAD tool SOLIDWORKS and allows the exchange of files in 3D format (DWG or PDF). Each project therefore has specific plans that are systematically validated before launching into production.
