R71 - Steel partial extension telescopic slide
This reinforced telescopic slide has two zinc-plated steel elements and offers partial extension. Designed for heavy loads and applications that require high strength, this slide is sturdy and secure.
The main feature of this telescopic slide is its ability to withstand stress. It is reinforced by balls which make it possible to withstand crushing and torsion torques. These balls guarantee optimal stability even in the most demanding conditions.
The telescopic slide is ideal for applications requiring strong resistance, such as industrial equipment, heavy cabinets or drawers with heavy loads. Thanks to its zinc-plated steel construction, it offers exceptional durability and long life, even when subjected to heavy use.
In summary, this reinforced telescopic slide is the ideal solution for heavy loads and applications that require maximum robustness. Its reliable design and reinforced features make it a perfect choice for those looking for a strong and durable telescopic slide.
Options available:
R71V lock open
R71F lock closed
R71VF open and closed interlock
R71DD Double development
Modification of the standard:
Development: This model can be increased by 10% or decreased. An increase in development decreases the maximum permissible load.
Custom lengths and strokes
Custom drilling plan
Uses at high temperatures
Other surface treatments (corrosion, hardness)
Vertical mounting (guillotine type)
